Parts Identification
18. Rear heated seat switch (if fitted)
19. Rear brake fluid reservoir
20. Relays (both sides)
21. Fuel tank and fuel filler cap
22. Front fork rebound damping
adjuster (models without Triumph
Electronic Suspension (TES))
23. Battery and main fuse
24. Radio antenna (models fitted with
audio system)
25. Front fork
26. Engine oil level sight glass
27. Oil filler cap
28. Rear brake pedal
29. Rear suspension spring pre-load
adjuster (models without Triumph
Electronic Suspension (TES))
30. Silencer
31. Rear brake disc
32. Rear indicator/Rear light assembly
chqt
18 19
27
22 23 24
282931
30
20
2526
21
32
