51
General Information
TPMS Sensor ID Number
An ID number for each tyre pressure sensor
is printed on a label which is attached to the
sensor. This number may be required by the
dealer for service or diagnostics.
If the TPMS has been fitted at the factory,
labels identifying the front and rear TPMS
sensor ID numbers will be affixed to the
spaces on page 51 .
If the TPMS is being fitted to the motorcycle
as an accessory, ensure that the dealer
records the front and rear TPMS sensor ID
numbers in the spaces provided below.
System Display
1. TPMS symbol
2. Tyre pressure display
The tyre pressure display can be accessed
through Trip 1 or Trip 2 (see page 38).
When the tyre pressure monitoring system
has been selected, — — PSI or BAR
(information on how to set the desired display
units can found on page 46) will be visible,
for each tyre, in the display screen until the
motorcycle is travelling at a speed greater
than 12 mph (20 km/h) and the tyre pressure
signal is received.
