Triumph Trophy SE User Manual

32
General Information
Multi-function Display Screen
Clock
The clock will display the time in 12 or
24 hour formats.
To change the display format from 12 to
24 hour, and set the time, see SETTINGS on
page 41 .
Ambient Air Temperature
The instruments will display the ambient air
temperature in ºC or ºF.
To change the temperature from ºC or ºF,
refer to Changing Units on page 47.
1. C l o c k
2. Temperature display
Gear Position Display
1. Gear position display (neutral
position shown)
2. Neutral light
The gear position display indicates which
gear (1 to 6) has been engaged. When the
transmission is in neutral (no gear selected),
the display will show N and the neutral light
will illuminate.
1. Gear position display (first gear
shown)
TRIP 1
MPH
0
10:08
N
26°C
1892
ODO
144.2
chdo
2
1
TRIP 1
MPH
0
10:08
N
26°C
1892
ODO
144.2
chdo
1
2
TRIP 1
MPH
0
10:08
1
26°C
1892
ODO
144.2
chdo
1

Triumph Trophy SE Specifications

General

Engine Type	Liquid-cooled, 12 valve, DOHC, in-line 3-cylinder
Displacement	1215 cc
Bore x Stroke	85 x 71.4 mm
Compression Ratio	11.0:1
Max Torque	120 Nm @ 6, 450 rpm
Fuel System	Multipoint sequential electronic fuel injection
Final Drive	Shaft
Clutch	Wet, multi-plate
Gearbox	6-speed
Frame	Aluminium beam twin-spar
Front Tyre	120/70 ZR17
Rear Tyre	190/55 ZR17
Fuel Tank Capacity	26 litres
Max Power	134 PS / 132 bhp @ 8, 900 rpm
Exhaust	Stainless steel 3 into 1
Front Suspension	WP 43mm upside down forks, adjustable rebound and compression damping
Rear Suspension	WP monoshock, adjustable rebound and compression damping
Front Brakes	Twin floating discs, Nissin 4-piston calipers, ABS
Rear Brakes	Single 282mm disc, Nissin 2-piston caliper, ABS
Front Wheel	Cast aluminium alloy 17 x 3.5in
Rear Wheel	Cast aluminium alloy 17 x 6.0in
Seat Height	800 mm (adjustable)
Wet Weight	301 kg
