Triumph Trophy SE User Manual

42
General Information
After entering either profile, press and release
the SCROLL button until the desired display
is highlighted. The display will scroll through
in the following order when pressing down
on the SCROLL button (it will scroll through
in the reverse order if up on the button is
pressed):
• LOAD - pressing the SELECT button will
load the selected profile and exit.
• EDIT - pressing the SELECT button
allows the current profile to be edited.
The profile is not loaded automatically
after it has been edited. It must be
loaded (see above) after it has been
saved.
The profile will be saved automatically
after editing.
• CANCEL - exits without loading or
editing the current profile.
Adjustment Menu
Note:
• The ADJUSTMENT screen can be
accessed when the motorcycle is
stationary or moving, however for
motorcycles fitted with TES it is only
possible to adjust TES Loading when
stationary.
Adjustment Menu
Warning
Any adjustments made to the motorcycle
when it is moving must be carried out only
when it is safe to do so.
After making adjustments it is
recommended to operate the motorcycle
in a safe area free from traffic to gain
familiarity with any new handling
characteristics.
Making adjustments to motorcycle settings
while travelling at high speed, during
cornering or braking, or in heavy traffic or
poor visibility, may result is loss of
motorcycle control and an accident.
10:08
N
22°C
TES LOADING
EXIT
TTC MODE
TES MODE
ADJUSTMENT
HEADLIGHT

Triumph Trophy SE Specifications

General

Engine Type	Liquid-cooled, 12 valve, DOHC, in-line 3-cylinder
Displacement	1215 cc
Bore x Stroke	85 x 71.4 mm
Compression Ratio	11.0:1
Max Torque	120 Nm @ 6, 450 rpm
Fuel System	Multipoint sequential electronic fuel injection
Final Drive	Shaft
Clutch	Wet, multi-plate
Gearbox	6-speed
Frame	Aluminium beam twin-spar
Front Tyre	120/70 ZR17
Rear Tyre	190/55 ZR17
Fuel Tank Capacity	26 litres
Max Power	134 PS / 132 bhp @ 8, 900 rpm
Exhaust	Stainless steel 3 into 1
Front Suspension	WP 43mm upside down forks, adjustable rebound and compression damping
Rear Suspension	WP monoshock, adjustable rebound and compression damping
Front Brakes	Twin floating discs, Nissin 4-piston calipers, ABS
Rear Brakes	Single 282mm disc, Nissin 2-piston caliper, ABS
Front Wheel	Cast aluminium alloy 17 x 3.5in
Rear Wheel	Cast aluminium alloy 17 x 6.0in
Seat Height	800 mm (adjustable)
Wet Weight	301 kg
