Triumph Trophy SE User Manual

50
General Information
Tyre Pressure Monitoring
System (TPMS) (if fitted)
Note:
• The Tyre Pressure Monitoring
System (TPMS) is standard
equipment on Trophy SE models,
and available as an accessory on
Trophy models. On Trophy models
TPMS must only be fitted by your
authorised Triumph dealer. The
TPMS display will then be activated
by your authorised Triumph dealer.
Function
Tyre pressure sensors are fitted to the front
and rear wheels. These sensors measure the
air pressure inside the tyre and transmit
pressure data to the instruments. These
sensors will not transmit the data until the
motorcycle is travelling at a speed greater
than 12 mph (20 km/h). Two dashes will be
visible in the display area until the tyre
pressure signal is received.
An adhesive label will be fitted to the wheel
rim to indicate the position of the tyre
pressure sensor, which is near the valve.
Warning
The daily check of tyre pressures must not
be excluded because of the fitment of the
TPMS. Check the tyre pressure when the
tyres are cold and using an accurate tyre
pressure gauge (see page 14 0 ).
Use of the TPMS system to set inflation
pressures may lead to incorrect tyre
pressures leading to loss of motorcycle
control and an accident.

Triumph Trophy SE Specifications

General

Engine Type	Liquid-cooled, 12 valve, DOHC, in-line 3-cylinder
Displacement	1215 cc
Bore x Stroke	85 x 71.4 mm
Compression Ratio	11.0:1
Max Torque	120 Nm @ 6, 450 rpm
Fuel System	Multipoint sequential electronic fuel injection
Final Drive	Shaft
Clutch	Wet, multi-plate
Gearbox	6-speed
Frame	Aluminium beam twin-spar
Front Tyre	120/70 ZR17
Rear Tyre	190/55 ZR17
Fuel Tank Capacity	26 litres
Max Power	134 PS / 132 bhp @ 8, 900 rpm
Exhaust	Stainless steel 3 into 1
Front Suspension	WP 43mm upside down forks, adjustable rebound and compression damping
Rear Suspension	WP monoshock, adjustable rebound and compression damping
Front Brakes	Twin floating discs, Nissin 4-piston calipers, ABS
Rear Brakes	Single 282mm disc, Nissin 2-piston caliper, ABS
Front Wheel	Cast aluminium alloy 17 x 3.5in
Rear Wheel	Cast aluminium alloy 17 x 6.0in
Seat Height	800 mm (adjustable)
Wet Weight	301 kg
