General Information
Brake and Clutch Lever
Adjusters
1. Adjuster wheel, brake lever shown
2. Arrow mark
An adjuster is fitted to both the front brake
and clutch levers.
The adjusters allow the distance from the
handlebar to the lever to be changed to one
of five positions for the front brake lever or
four positions for the clutch lever, to suit the
span of the operator's hands.
To adjust the lever, push the lever forward
and turn the adjuster wheel to align one of
the numbered positions with the arrow mark
on the lever holder.
The distance from the handlebar grip to the
released lever is shortest when set to number
five, and longest when set to number one.
Warning
Do not attempt to adjust the lever with the
motorcycle in motion as this may lead to
loss of motorcycle control and an accident.
After adjusting the lever, operate the
motorcycle in an area free from traffic to
gain familiarity with the new lever setting.
Do not loan your motorcycle to anyone as
they may change the lever setting from the
one you are familiar with causing loss of
control or an accident.
2
1
chde

Triumph Trophy SE Specifications

General

Engine Type	Liquid-cooled, 12 valve, DOHC, in-line 3-cylinder
Displacement	1215 cc
Bore x Stroke	85 x 71.4 mm
Compression Ratio	11.0:1
Max Torque	120 Nm @ 6, 450 rpm
Fuel System	Multipoint sequential electronic fuel injection
Final Drive	Shaft
Clutch	Wet, multi-plate
Gearbox	6-speed
Frame	Aluminium beam twin-spar
Front Tyre	120/70 ZR17
Rear Tyre	190/55 ZR17
Fuel Tank Capacity	26 litres
Max Power	134 PS / 132 bhp @ 8, 900 rpm
Exhaust	Stainless steel 3 into 1
Front Suspension	WP 43mm upside down forks, adjustable rebound and compression damping
Rear Suspension	WP monoshock, adjustable rebound and compression damping
Front Brakes	Twin floating discs, Nissin 4-piston calipers, ABS
Rear Brakes	Single 282mm disc, Nissin 2-piston caliper, ABS
Front Wheel	Cast aluminium alloy 17 x 3.5in
Rear Wheel	Cast aluminium alloy 17 x 6.0in
Seat Height	800 mm (adjustable)
Wet Weight	301 kg
