Trotec Speedy 360 flexx Operation Manual

Speedy 360
BA 8032_2.2_EN (05/2016) 29 / 90
www.troteclaser.com
4.2.1.1.1.1.39
4.2.1.1.1.1.40
4.2.1.1.1.1.41 • Options
4.2.1.1.1.1.42
Rotary attachment
Cone, roll or combined version, tiltable
Max. workpiece length cones: 21.6 in (550 mm)
Max. workpiece length rolls: Ø ≥ 2.2 in (58 mm) = 26.7 in (679 mm), Ø ≤ 2.2 in
(58 mm) = 29.3 in (745 mm)
Max. workpiece diameter cones: 8.1 in (207 mm), depending on inserted lens
Max. workpiece diameter rolls: 3.7 in (96 mm), depending on inserted lens
4.2.1.1.1.1.43 JobControl
®
Vision
4.2.1.1.1.1.44 Registration marks detection and compensation system
4.2.1.1.1.1.45 Max. working area without camera: 32  20 in (813  508 mm)
4.2.1.1.1.1.46 Max working area with camera: 31.5  20 in (801  508 mm)
Vacuum table
Vacuum effect for fixation of thin or wavy materials
4.2.1.1.1.1.47 Honeycomb cutting tabletop
4.2.1.1.1.1.48 Perfect in combination with vacuum table;
4.2.1.1.1.1.49 0.5 in (12.7 mm) or 0.25 (6,4 mm) nominal comb size
Aluminum cutting grid table
Particularly suitable for cutting tasks with parts smaller than 4 in (100 mm)
Acrylic cutting grid table
For reflection-free cutting of tasks with parts smaller than 4 in (100 mm)
4.2.1.1.1.1.50 Aluminum slat cutting table
4.2.1.1.1.1.51 Particularly suitable for cutting tasks of thicker materials and parts bigger than 4
in (100 mm); removable aluminum slats
4.2.1.1.1.1.52 Acrylic slat cutting table
4.2.1.1.1.1.53 For reflection-free cutting for tasks with thicker materials and parts bigger than 4
in (100 mm); removable acrylic slats
4.2.1.1.1.1.54 Sonar Technology
TM
4.2.1.1.1.1.55 For fast and easy focusing on the surface of the work piece with ultrasonic
sensor; higher accuracy in comparison to manual focusing
Gas-Kit light (for compressed
air connection)
For control of compressed air (free of mechanical dust, water and oil) max. flow
rate 150 l/min (40 gpm) with max. 10 bar (145 psi); max. limit 4 bar on working
head, connection on the machine with external hose diameter of 0.23 in (6mm)
UniDrive
Increased flexibility by the use of different operating systems e.g. MAC and
multiple design stations, workflow optimization
TroCAM
CAD / CAM software for perfect cutting results; including nesting-function, lead-
in/lead-out, tool paths
4.2.1.1.1.1.56 MCO
4.2.1.1.1.1.57 Multi-Color Option for stamp pad cutting
4.2.1.1.1.1.58 • Control System
4.2.1.1.1.1.59
Software
JobControl X Expert
Laser Power
Adjustable 0 – 100%
Interface hardware
USB
Interface software
ASCII, HPGL, JobControl
4.2.1.1.1.1.60
4.2.1.1.1.1.61 • Laser Equipment flexx
Laser tube CO
2
Sealed-off CO
2
laser, maintenance-free
Laser power: 40 - 120 W, air cooled
Wavelength
10.6 µm
Laser tube fiber
Pulsed fiber laser, maintenance-free
Laser power: 10 W 20 W, 30 W, 50 W
Wavelength
1064 nm
4.2.1.1.1.1.62
4.2.1.1.1.1.63
4.2.1.1.1.1.64
4.2.1.1.1.1.67
