8.8.3 Engraving
1. Create a graphic with the help of the graphics software. Select the printer driver and rotary
attachment, and enter the diameter of the workpiece.
2. Perform the settings for size and orientation in the JobControl
®
menu “Plate” > “Setup Plate” and
choose - if necessary - the engraving material. You can determine the orientation of the graphic on
the workpiece with the option “Job Orientation”.
3. In the menu “Settings “> “Options” > “Accessories”, select the option “Rotary Engraving” and enter
the diameter of the object (see Fig. 6).
If the diameter has already been entered in the printer driver, the size is automatically transferred
into JobControl
®
.
4. Double-click on the job in the waiting list to place it on the plate.
5. Position the laser head over the workpiece.
6. Start the engraving process.
See the Software Manual for additional functions.
When using the rotary engraving attachment, the autofocus is automatically
deactivated.
