Speedy 360
BA 8032_2.2_EN (05/2016) 49 / 90
6.4 Unpacking the machine
Only trained and authorized personnel are permitted to transport and unpack the machine.
To avoid falling off of any wooden parts or tipping of the machine, be very careful when opening the
transport case.
Keep the original packaging case, in case the machine needs to be relocated or
transported over longer distances.
Dispose all waste according to the applicable waste disposal law.
The lens unit should be unpacked only after installation of the machine. The lenses are
high-quality optical components which must be kept clean in order to ensure optimum
marking results. Never touch the lenses with bare fingers!
The following steps give you an overview of the unpacking of the laser machine.
1. Position the transport case vertically on level
ground (using a pallet truck or forklift).
Remove any vertical tightening straps.
2. First remove the top and afterwards the side
plates of the transport case.
3. Slide out the two wooden rails in the form of ramps
that are stored beneath the machine.
4. To secure the machine against moving, the
wheels are locked using wooden blocks.
In order to remove those blocks, put the two
wooden rails together, push the upper part of the
rails under one side of the machine and press
down the rail in order to reach a levering effect.
5. Now you can pull out the blocks. Repeat those
steps on the opposite side of the machine.
