Trotec Speedy 360 flexx Operation Manual

Speedy 360
BA 8032_2.2_EN (05/2016) 60 / 90
www.troteclaser.com
8.4 Table placement
1. Place a suitable table on the multifunctional
base frame.
2. Fixate the table by pressing the push buttons.
All table variants rest on the base
frame. However the ferromagnetic
engraving table may also be placed
directly on the mounting frame
without the base frame.
For more details about the available
table variants, see chapter “Tables”.
Maximum material load is for static
loads: up to 220 lbs. (100 kg) and
dynamic loads: up to 66 lbs. (30 kg).
Damage to the multifunctional base frame or impairment of the exhaust function
When workpieces are processed directly in the multifunctional base frame without a table,
the base frame can be damaged, and impairment of the exhaust function is possible.
- Process workpieces only on suitable tables.
