Trotec Speedy 360 flexx Operation Manual

Speedy 360
BA 8032_2.2_EN (05/2016) 28 / 90
www.troteclaser.com
4.2 Data sheet
• Mechanics
4.2.1.1.1.1.1 Working area
4.2.1.1.1.1.2 32  20 in (813  508 mm)
4.2.1.1.1.1.3 Loading area
4.2.1.1.1.1.4 35  23.6 in (890  600 mm)
4.2.1.1.1.1.5 Max. height of work piece
1.5 ", 2.0 ": 8.2 in (210 mm) incl. working table / 11 in (280 mm) without working
table
2.0 " clearance lens, 2.5": 7.7 in (197,5 mm)
2.85 " flexx lens: 7.4 in (188 mm)
3.2 ": 7 in (179 mm)
4.2.1.1.1.1.6 4.0 ": 6.2 in (159 mm)
4.2.1.1.1.1.7 5.0 ": 5.2 in (133 mm)
4.2.1.1.1.1.8 Working tables
4.2.1.1.1.1.9 Standard: ferromagnetic engraving table
4.2.1.1.1.1.10 Optional: multifunctional table concept (multifunctional table base frame including
one working table of choice – vacuum table, aluminum cutting grid table, acrylic
cutting grid table, aluminum slat cutting table, acrylic slat cutting table); rulers in
inch or mm
4.2.1.1.1.1.11 Additional available: honeycomb cutting tabletop with 0.5 (12,7 mm) or 0.25 (6,4
mm) nominal comb size
4.2.1.1.1.1.12 Electronic, programmable Z-axis with servo motor
4.2.1.1.1.1.13 Speed of motion system
4.2.1.1.1.1.14 139 in/sec (355 cm/sec.) CO
2
4.2.1.1.1.1.15 78 in/sec (200 cm/sec.) fiber
4.2.1.1.1.1.16 Acceleration
4.2.1.1.1.1.17 5g
4.2.1.1.1.1.18 Motor
4.2.1.1.1.1.19 Brushless DC servomotor
4.2.1.1.1.1.20 Encoder
4.2.1.1.1.1.21 Increment measuring system
4.2.1.1.1.1.22 Lenses
4.2.1.1.1.1.23 Standard: 2.85 " flexx lens
4.2.1.1.1.1.24 Optional CO
2
: 1.5 ", 2.0 ", 2.0 " clearance lens – 0.5 in (12,5 mm) more distance
from the material than standard lenses, 2.5 ", 4.0 "
4.2.1.1.1.1.25 Optional fiber: 3.2", 5.0"
4.2.1.1.1.1.26 Addressable accuracy
4.2.1.1.1.1.27 5 μm
4.2.1.1.1.1.28 Repeat accuracy
4.2.1.1.1.1.29 <± 0.0006 in (0,015 mm)
Accuracy to size of parts
Depending on material and process
4.2.1.1.1.1.30 Max. material load
4.2.1.1.1.1.31 Static: up to 220 lbs. (100kg) / Dynamic: up to 66 lbs. (30 kg)
4.2.1.1.1.1.32 Exhaust
4.2.1.1.1.1.33 Surface exhaust via rear of the engraving cabinet, table exhaust with vacuum and
cutting table
4.2.1.1.1.1.34 Standard features
4.2.1.1.1.1.35 Ergonomic access to working area, harsh environment protection kit, coaxial air
assist (without pump), Light Bar Focus (electro-optic autofocus), laser pointer
(655 nm, <0,99mWcw), 2.85 " flexx lens by default (can be replaced free of
charge with 1.5 " lens, 2.0 " lens, 2.0" clearance lens, 2.5 " lens, 3.2" lens, 4.0"
lens or 5.0 " lens, ferromagnetic engraving table, nozzles (Ø3 mm und Ø7 mm),
LED lighting, USB connection, JobControl
®
Expert Software, iOS App
4.2.1.1.1.1.36 Optional
4.2.1.1.1.1.37 Air assist incl. compressor, rotary attachment, gas-kit light, temperature sensor
incl. emergency stop button, Sonar Technology
TM
(ultrasonic auto-focus),
multifunctional table concept incl. one working table free of charge (vacuum table,
aluminum cutting grid table, acrylic cutting grid table, aluminum slat cutting table,
acrylic slat cutting table);
4.2.1.1.1.1.38 Honeycomb cutting table top with 0.5 in (12.7 mm) or 0.25 (6,4 mm) nominal
comb size
