Appendix A Reversing Oven Door
Amendment 10
11 May 2015
Reversing the Oven Door
NOTE: This operation should only be carried out by a
suitably competent person.
Remove the Oven Door Inner Glass.
1.
Open the oven door and open the
door inner glass.
2. Remove screw securing in
ner
gl
ass retaining clip and remove
clip
.
3. Lift up inner glass and remove,
ensur
ing that pivot spac
er is
removed from
lower inner gla
ss
pi
vot and retained.
4. Remove black plastic plugs from
top and bottom of door and fit
to
hole
s where inner glass pivots
were removed fr
om.
Remove t
he Oven Door.
5. Remove the door roller catch and blanking plate from th
e
i
nside of the door and swap these over.
6. Whilst supporting door, unscr
ew
and remo
ve top door pivot bolt
from top door hinge assembly.
7. Remove door and lay on a flat
surfa
ce or workbench.
8. Unscrew screws securing th
e
door handle rem
ove door handle.
9. Remove top door hinge and fit to
bottom opposite corner of door.
10.
Remove bottom door hinge and
fit to top opposite corner of door
.
Remove Top
Door Pivot Bolt.
Remove Top Door Hinge
Remove Handle
Securing Screws
11. Remove inner glass latching
stud
s and fit to opposite side of
door using Loctite 243 to secu
re.
12.
Turn door handle over and fit to other end of d
oor where
hinge
s were removed from. Ensure Flat of handle is to
the
out
side.
Remove Upper and Lower Door Hinges and Door Catch.
13. Remove bottom door pivot bolt
and spacers and fit pivot bolt to
top door hinge assembly (as th
is
wi
ll be swapped over and fitt
ed
to b
ottom of other side of oven).
14.
Remove the 4 blanking screws
from front of oven.
15.
Remove Hinge Plate from
top of
o
ven and fit diagonally opposite,
to lower corn
er.
16.
Remove Hinge Pl
ate from
b
ottom of oven and
fit
di
agonally opposite, to
upper
corne
r
.
17.
Fit screws removed at It
em 14
above to wher
e hinges
were
fi
tted.
Remove these screws to remove
top and bottom hinges.
Bottom Door Pivot
Bolt and Spacers.
Remove screws top and bottom
and fit to where hinges removed
from.
Remove Latching Studs
Swap Roller Catch and
Blanking Plate over.
Remove Screw
and Retaining
Fit Blanking Plugs.
