40
Appendix A Reversing Oven Door
Amendment 10
11 May 2015
18. Remove Blanking Screw and Door Catch from front of oven
and swap around (refer ‘Adjusting Door Catch’).
19. Fit door spacers removed at Item 13 previously, to lower hi
nge
pi
vot bolt.
Oven Door Re-Fitting
Fit the Door.
1. Refit oven door by locating bott
om
of d
oor onto bottom hinge plat
e
pi
vot bolt and spac
ers.
2.
Fit top of door into top hinge pl
ate
and s
ecure with top pivot bolt
.
Fit Inner Glas
s to Door.
NOTE: It is important to ensure that the inner glass is fitted
correctly and that the glass pivots at the hinge end
of the door and not the handle end.
3. Fit pivot spacer removed at Item 3 on previous page, to th
e
l
ower inner glass pivot and locate inner glass lower pivot into
position on inside of door.
4. Locate top pivot of inner glass into
top of door and secure in position
with inner glass retaining clip.
5. Lift inner glass up onto locking
catch to lock glass into position
.
Top Door Pivot Bolt.
Inner Glass Locking Catch
Screw and Retaining Clip.
Adjust Door for Correct Alignment.
Check alignment and operation of the
door. Ensure that the door is
correctly aligned horizontally and
vertically.
1.
To align, slacken off
the upper and
lower hinge plate
s and correc
tly
alig
n the door. Re-tighten bo
th
hinge plates.
2.
Check that the roller ca
tch
corre
ctly retains door in the closed
position.
3. To adjust, slightly loosen screws
securing roller catch and close the
door. The roller catch wi
ll
c
entralise itself.
4. Open door and tighten roller ca
tch
securing screws.
Adjusting Door Catch
If the door sealing requires adjustment, carry out the following to
adjust the door catch:-
1. Check that the door seals correctly when closed, by plac
ing a
s
heet of paper between the door
and the seal
.
2.
Close the door on th
e paper and
attem
pt to withdraw the paper by
firmly tugging on the paper.
The
paper s
hould just pull out wi
th
s
ome resistance but without
tearing the paper.
3. To adjust the door catch, loosen the locking nut on the door
cat
ch:
-
a.
If the paper withdraws easily,
screw the door catch ‘In’
by ½ a turn
and repeat the test above until adjusted
corre
ctly.
b. If the paper cannot be withdrawn and the door springs
open,
screw the door catch ‘Out’ by ½ a turn
and
rep
eat the test above until adjusted correctly.
4.
Tighten the locking nut on the door catch.
Slacken these screws to adjust
door vertically - horizontally.
Blanking Screw
Door Catch
Locking Nut
To Next Page
