Page #67 background image
Replacement Parts List
19
ITEM PART No. DESCRIPTION *RPL
4
M026216 DRAWER WA D
M234319
CONDENSATE CHANNEL (P8 / P12)
D
M236599
CONDENSATE CHANNEL (P10)
D
6
M022758
DOOR CATCH PLATE C
7
M234313
TOP COVER (P8 / P12)
D
M236463
TOP COVER (P10)
D
8
M234315
SIDE PANEL (P8)
D
M236464
SIDE PANEL (P10)
D
M234316
SIDE PANEL (P12)
D
9
M234216
CASTOR 75mm RIGID RUBBER D
10
M234217
CASTOR 75mm SWIVEL RUBBER D/BRAKE D
11
M234856
HINGE SPACER D
M236299
DOOR GASKET D
12
M234447
KNOB INDEXED C
13
M
234334
CONTROL PANEL ASSEMBLY (P8M) °F
D
M234717
CONTROL PANEL ASSEMBLY (P8M) °C
D
M236526
CONTROL PANEL ASSEMBLY (P10M) °F
D
M236527
CONTROL PANEL ASSEMBLY (P10M) °C
D
M234335
CONTROL PANEL ASSEMBLY (P12M) °F
D
M234718
CONTROL PANEL ASSEMBLY (P12M) °C
D
5
Main Assembly (continued)
*Recommended Parts Level
RPL
Number of Units In-Service
A+B 5-10
A+B+C 10-50
A 1-5
A+B+C+D 50+
