Tyco Electronics Galaxy SC Controller J85501F-1
7 - 5 Feature Descriptions Issue 13 February 2001
The following alarm test features may be configured or viewed only via
the T1.317 interface:
Description Description (default: Alarm Test n)
State Active alarm test state (1 = active; 0 = inactive)
Rectifier failure list List of rectifiers that have failed alarm test
Remote alarm test enabledAllow T1.317 initiated alarm test
Duration Duration of each alarm contact (range: 5
seconds to 300 seconds/5 minutes; default: 60
seconds)
Power Critical enabled Activate Power Critical alarm contact during
alarm test
Power Major enabled Activate Power Major alarm contact during
alarm test
Power Minor enabled Activate Power Minor alarm contact during
alarm test
Major Fuse enabled Activate Major Fuse alarm contact during alarm
test
Minor Fuse enabled Activate Minor Fuse alarm contact during alarm
test
Battery on Discharge enabled Activate Battery on Discharge alarm contact
during alarm test
AC Fail enabled Activate AC Fail alarm contact during alarm test
Rectifier Fail Alarm enabledActivate Rectifier Fail Alarm alarm contact
during alarm test
Very Low Voltage enabledActivate Very Low Voltage alarm contact during
alarm test
High Voltage enabled Activate High Voltage alarm contact during
alarm test
Controller enabled Activate Controller alarm contact during alarm
test
User Relay 1 enabled Activate User Relay 1 alarm contact during
alarm test
User Relay 2 enabled Activate User Relay 2 alarm contact during
alarm test
In addition, three alarm events are associated with the alarm test feature:
Alarm Test Active Alarm test is currently active
Alarm Test Failed Alarm test has failed (user clearable)
Alarm Test Aborted Alarm test has been aborted by an alarm (user
clearable)
