Tyco Electronics Galaxy SC Controller J85501F-1
3 - 18 Installation Issue 13 February 2001
Note: The modification of control cables for rectifier identification
(cutting TP leads) is not required for use with Galaxy SC.
Figure 3-4: Control Cable Connectors
Correct Orientation for
Three Types of Control Cable
Connectors
(MCS Compatible L-31)
12
AMP 1-102
24
Rectifier Interface Module
1
13
12
24
13
12
AMP 1-102
24
13
1
