Tyco Galaxy SC Controller User Manual

Tyco Electronics Galaxy SC Controller J85501F-1
Issue 13 February 2001 Configuration 4 - 5
MOR Measurement Out Of Range Minor RM None
MTC Module Type Conflict Minor RM None
NNC Number Not Configured Warning None None
OSA Open String Minor BAT None
PCF PC Power Fuse Minor CTLR CTLR
PFD Password At Default Warning None None
PGI Program Line Invalid Major None None
PHT Processor Halt RO None None
POR* Number Did Not Respond Warning None None
RBF Regulation Battery Fuse Minor CTLR CTLR
RIC Rectifier Incomplete Config Warning None None
RPF Remote Peripheral Fuse Major CTLR CTLR
RPI* Rectifier/Plant Inconsistency Warning None None
RTL Reserve Time Low Minor BATT None
SNC Shunt Not Configured Warning None None
STF* Self Test Failed Minor CTLR CTLR
TPA Thermal Probe Failure Minor CTLR CTLR
URC User Relay Conflict Warning None None
VLA Very Low Voltage Critical BATT VLV
VSF Sense/Control Fuse Major CTLR CTLR
ZID ID Not Configured Major RECT None
Table 4-B: Plant Alarm Severity, LED, and Relay Defaults
Symbol
(* denotes Latched
alarm event)
Default Designation
Default
Severity
Default LED Default Relay
Table 4-C: Rectifier Alarm Defaults
Symbol Default Designation
Default
Severity
Default LED Default Relay
ACF AC Fail Minor AC ACF
CLM Rectifier Current
Limit
RO None None
