Tyco Galaxy SC Controller User Manual

Tyco Electronics Galaxy SC Controller J85501F-1
4 - 4 Configuration Issue 13 February 2001
CNF2 Contactor 2 Failed Major None None
CNF3 Contactor 3 Failed Major None None
CN01 Contactor 1 Open Major None None
CN02 Contactor 2 Open Major None None
CN03 Contactor 3 Open Major None None
COF* Queue Overflow Warning None None
COR* Number Did Not Respond Warning None None
CPA Circuit Pack Fail Major CTLR CTLR
CRA Controller Fail Major CTLR CTLR
CRF Controller Fuse Major CTLR CTLR
DID Rectifier ID Conflict Major RECT None
EMD Energy Management
Disabled
Warning None None
EPD* Excess Plant Drain Minor RECT None
EPR* External Password Reset Warning None None
ERD Excess Rectifier Drain Minor RECT None
ETO Engine Transfer Timeout Minor AC None
EXL* Excessive Login Attempts Warning None None
FAJ External Fuse Major Major DIST MJF
FAN External Fuse Minor Minor DIST MNF
HCL History Cleared RO None None
HFV High Float Voltage Minor RECT None
HVA High Voltage Major RECT HV
LMR Limited Recharge Minor RECT None
LVD Low Voltage Disconnect Minor BAT None
LVDA Low Voltage Disconnect Fail Minor BAT None
MCM Major Communications Fail Major CTLR None
MDF Module Failure Minor RM None
MFA Multiple Rectifier Fail Major RECT RFA
Table 4-B: Plant Alarm Severity, LED, and Relay Defaults
Symbol
(* denotes Latched
alarm event)
Default Designation
Default
Severity
Default LED Default Relay
