Tyco Galaxy SC Controller User Manual

Tyco Electronics Galaxy SC Controller J85501F-1
Issue 13 February 2001 Configuration 4 - 3
Table 4-B: Plant Alarm Severity, LED, and Relay Defaults
Symbol
(* denotes Latched
alarm event)
Default Designation
Default
Severity
Default LED Default Relay
AAC ACO Active RO None None
ABS Alarm Battery Supply Fuse Major CTLR CTLR
AMJ Auxiliary Major Major None None
AMN Auxiliary Minor Minor None None
ATA Alarm Test Active RO None None
ATB* Alarm Test Aborted RO None None
ATF* Alarm Test Failed Warning None None
BBL Memory Backup Battery
Low
Warning None None
BCA Battery Type Conflict Warning None None
BDA Battery on Discharge Major BD BD
BFA Battery Test failed Minor BAT None
BID Bay Interface ID Conflict Major CTLR CTLR
BPF Battery Power Fuse Major CTLR CTLR
BTA Battery Test Active RO BD BD
BTF Battery Thermal Fuse Major CTLR CTLR
BTJ Battery Thermal Major Major BAT None
BTN Battery Thermal Minor Minor BAT None
CCH* Configuration Changed RO None None
CDFA Converter Distribution Fuse Major DIST MJF
CDID Converter ID Conflict Major RECT None
CEA Connected Equipment Alarm Minor None None
CFA Converter Fail Minor RECT None
CFJ Converter Fan Major Major Rect None
CFN Converter Fan Minor Minor RECT None
CLC Clock Changed RO None None
CMA Minor Communications Fail Minor CTLR None
CMFA Multiple Converter Fail Major RECT None
CNF1 Contactor 1 Failed Major None None
