Tyco Electronics Galaxy SC Controller J85501F-1
3 - 6 Installation Issue 13 February 2001
• Never hand a circuit pack from a grounded to a non-grounded
person or vice-versa.
1. Open the front door of the Galaxy SC by pulling down on the top
sides of the door. Assure that all necessary circuit packs are
provided. Refer to Figure 3-1 and Table 3-A.
Each of the Basic Controller packs is required, but BJC Rectifier
Interface Packs are only necessary for the Rectifier Interface
Module positions in use. Refer to the appropriate
engineering/ordering information to determine the optional packs
necessary on the Intelligent side, if any.
2. Disengage all of the equipped packs by pulling down on the circuit
pack latch and sliding the board away from the backplane. Do not
remove the board completely from the guides.
Table 3-A: Standard Galaxy SC Controller Circuit Packs
Location
Board
Code
Function
Basic Controller Boards
Far Right BJE Relay/alarm
2nd From
Right
BJA Basic Controller Power Board
3rd From Right BJC
Rectifier Interface for first 8
Rectifiers (more if BJC3)
4th From Right BJC
Rectifier Interface for Rectifiers
9-16 (if equipped; more if BJC3)
5th From Right BJC
Rectifier Interface for Rectifiers
17-24 (if equipped; more if BJC3)
6th From Right Reserved for future development
7th From Right BJB Basic Controller
