Tyco Electronics Galaxy SC Controller J85501F-1
4 - 2 Configuration Issue 13 February 2001
Table 4-A: Voltage Threshold Ranges and Default Values
Low High Default
Very Low Voltage (VLV)
24V
20.00 25.00 23.00
48V
40.00 51.00 46.00
Battery on Discharge (BD)
24V Float
23.00 28.00 25.00
24V Boost
23.00 28.00 25.00
48V Float
46.00 55.00 51.00
48V Boost
46.00 55.00 51.00
High Float Voltage (HFV)
24V Float
24.75 29.75 26.50
24V Boost
25.75 31.75 26.50
48V Float
50.00 60.00 53.00
48V Boost
52.00 60.00 53.00
High Voltage Shutdown Alarm (HV)
24V Float
24.75 29.75 26.8
24V Boost
25.75 31.75 26.8
48V Float
50.00 60.00 53.6
48V Boost
52.00 60.00 53.6
Rectifier On Threshold (ROT)
24V
20.00 25.00 22.00
48V
40.00 50.00 44.00
Note: For explanation of typical settings, refer to Appendix F.
