Tyco Galaxy SC Controller User Manual

Tyco Electronics Galaxy SC Controller J85501F-1
3 - 30 Installation Issue 13 February 2001
Table 3-I: MCS/Galaxy Alarm Connections
MCS Connections Equivalent Galaxy Connections
Signal Wire Color MCS TB1 Pin #Galaxy TB & Pin # Connect to Signal
UPF 1 TB3-2 CTLR
UPFR 2 TB3-18 CTLR
EQ 3 TB3-40 TEQ
EQR 4 TB3-24 TRTN
S1(A) 5 TB2-13 BD (C)
S1(A) 6 TB2-29 BD (R)
S1(B) 7 TB3-1 HV (C)
S1(B) 8 TB3-17 HV (R)
S1(C) 9 TB2-15 RFA (C)
S1(C) 10 TB2-31 RFA (C)
S1(D) 11 TB2-16 VLVC
S1(D) 12 TB2-32 VLVR
S1(E) 13 TB2-11 MJF (C)
S1(E) 14 TB2-27 MJF (R)
S1(F) 15 TB2-41 PMNEO
S1(F) 16 TB2-25 PMNER
S1(G) 17 TB2-38 PMJEO
S1(G) 18 TB2-22 PMJER
FAN 19 TB3-6 FAN
FAJ 20 TB3-5 FAJ
ABS0 21 TB3-30 ABS1
FG 22 Chassis Lug or FG Chassis Lug or FG
ABS1 23 TB3-46 ABS2
A24
TB2-10
TB2-26 must be
grounded
SI (C)
ABS2 25 TB3-31 ABS3
D26TB2-42ALRMD
ABS3 27 TB3-47 ABS4
BD 28
TB2-13
TB2-29 must be
grounded
BD
TR1 29 TB3-8 TR1
TR2 30 TB3-9 TR2
TR3 31 TB3-10 TR3
TR4 32 TB3-11 TR4
