Tyco Electronics Galaxy SC Controller J85501F-1
Issue 13 February 2001 Safety 9 - 3
inherently limited transformer rated 30 vac max. The typical operating
current from each output is less than 0.5 amps (with a maximum of 85
modules attached).
Connectors on the backplane contain communication circuits, current
limited signals, and 19 to 30vdc or 36 to 60vdc control signals fused at
1-1/3 amp.
The PCPWR connector on the fuse board is fused at 3 amps. This is
intended for supplying dc power to devices located next to the
controller.
The BATT PRED connector on the fuse board contains current limited
circuitry.
Use only the screws provided for mounting the equipment in a frame or
equivalent screws no smaller than No. 12-24 x 5/8. A minimum of 4
screws should be used on each side.
Grounding/bonding for the equipment can be provided through the
mounting brackets. In this case, make sure the frame is suitably
grounded. There is also a place provided on the equipment for the
connection of a grounding conductor.
This controller uses a replaceable lithium battery:
WARNING
Danger of explosion or fire if lithium battery is incorrectly
replaced. Replace only with Panasonic BR2032 or an equivalent
recommended by the manufacturer. Spare batteries may be ordered
per the product documentation. Lithium batteries may be regulated
wastes (due to reactivity) when disposed of. Always discard used
batteries according to applicable local, state, and federal
regulations.
Notice:
The battery manufacturer, Panasonic, has provided the following
information regarding its product. Caution: Risk of fire, explosion,
and burns. Do not recharge, disassemble, heat above 100° C (212°
F), or incinerate. Dispose of used batteries promptly. Keep away
from children.
