Tyco Electronics Galaxy SC Controller J85501F-1
Issue 13 February 2001 Safety 9 - 5
The symbols may sometimes be accompanied by some type of
statement; e.g., “Hazardous voltage/energy inside. Risk of injury. This
unit must be accessed only by qualified personnel.”
This symbol is used to identify the
presence of a hot surface. It may also be
accompanied by a statement explaining
the hazard. A symbol like this with a
lightning bolt through the hand also
means that the part is or could be at
hazardous voltage levels.
This symbol is used to identify the
presence of a hot surface. The marked
item should not be touched without taking
care.
This symbol is used to identify the
protective safety earth ground for the
equipment.
This symbol is used to identify other
bonding points within the equipment.
