Tyco Electronics Galaxy SC Controller J85501F-1
Issue 13 February 2001 T1.317 Objects and Attributes Appendix B - 19
Table B-14: Remote Communication Objects and Attributes
Related Commands
ATTRIBUTE MNEM TYPE CHA OPE MET CON BACKUP VALUE
Modem MDM
Identifier IDE TEXT MD1
Description DES TEXT X X X Modem Port 1
State STT TEXT USER,SUPER-USER,
ADMINISTRATOR,TL1,LO
GOUT
Data Bits DBT NUMBER X X X 7,8
Parity PRY TEXT X X X O,E,N
Stop Bits SBT NUMBER X X X 1,2
Time-Out TMO NUMBER X X X 0(disabled) - 45:5 minutes
Handshaking HSH TEXT X X X NO,SW
Number of Rings Before Answer NRG NUMBER X X X 2-15
Write Enable WRE NUMBER X X X 0:disable 1:enable (HW,SW)
Modem Initialization String INS TEXT X X X up to 40 characters “” assigns the
default string
Local RS-232 Port LPT
Identifier IDE TEXT LP1
Description DES TEXT X X X Local Port 1
State STT TEXT USER,SUPER-USER,
ADMINISTRATOR,TL1,LO
GOUT
Baudrate BDR TEXT X X X AUTO, 300,1200,2400,
4800,9600,19200
Data Bits DBT NUMBER X X X 7,8
Parity PRY TEXT X X X O,E,N
Stop Bits SBT NUMBER X X X 1,2
Time-Out TMO NUMBER X X X 0(disabled) - 45:5 minutes
Handshaking HSH TEXT X X X NO,HW,SW
Application APP TEXT X X X TERMINAL, EVENT LOG
(HW,SW)
Write Enable WRE NUMBER X X X 0:disable 1:enable (HW,SW)
Auxiliary Port AUX
Identifier IDE TEXT AU1
Description DES TEXT X X X Auxiliary Port 1
State STT TEXT USER,SUPER-USER,
ADMINISTRATOR,TL1,LO
GOUT
Baudrate BDR TEXT X X X AUTO, 300,1200, 2400,4800,
9600,19200
Data Bits DBT NUMBER X X X 7,8
Parity PRY TEXT X X X O,E,N
Stop Bits SBT NUMBER X X X 1,2
Time-Out TMO NUMBER X X X 0(disabled) - 45 minutes
Handshaking HSH TEXT X X X NO,SW
Application APP TEXT X X X TERMINAL, TL1, SAPO
Write Enable WRE NUMBER X X X 0:disable 1:enable (HW,SW)
