Tyco Electronics Galaxy SC Controller J85501F-1
Issue 13 February 2001 T1.317 Objects and Attributes Appendix B - 21
Table B-16: Inventory Objects and Attributes
Related Commands
ATTRIBUTE MNEM TYPE CHA OPE MET CON BACKUP VALUE
Plant Inventory PLI
Identifier IDE TEXT PLI1
Description DES TEXT X X X Plant Inventory 1
Plant Installation Date IDT TEXT X X X 8 char (default: “”)
Plant Service Date SDT TEXT X X X 8 char (default: “”)
Last Inventory Entry Date EDT TEXT X X X 8 char (default: “”)
Nominal Plant Output Voltage NOV TEXT X X X 6 char (default: “”)
Nom Boost Condition NBC TEXT X X X 6 char (default: “”)
Nom Equalize Condition NEQ TEXT X X X 6 char (default: “”)
Nom Load Share Condition NLS TEXT X X X 6 char (default: “”)
Nom Float HV Threshold NFH TEXT X X X 6 char (default: “”)
Nom Boost HV Threshold NBH TEXT X X X 6 char (default: “”)
Nom Float HFV Threshold NFF TEXT X X X 6 char (default: “”)
Nom Boost HFV Threshold NBF TEXT X X X 6 char (default: “”)
Nom BD Threshold NBD TEXT X X X 6 char (default: “”)
Nom VLV Threshold NVL TEXT X X X 6 char (default: “”)
Nom Plant Capacity Threshold NPC TEXT X X X 6 char (default: “”)
Installed Rectifier Capacity IRC TEXT X X X 6 char (default: “”)
Shunt Voltage SHV TEXT X X X 6 char (default: “”)
Shunt Amperes SHA TEXT X X X 6 char (default: “”)
Low Voltage Disconnect LVD TEXT X X X 6 char (default: “”)
Rectifier Inventory REI
Identifier IDE TEXT X GI01 to GI24
Description DES TEXT X X X Rectifier Inventory n
Type TYP TEXT X X X 15 char (default: “”)
Technology TEC TEXT X X X 6 char (default: “”)
Capacity CAP TEXT X X X 6 char (default: “”)
CLEI Code CLEI TEXT X X X 10 char (default: “”)
Serial Number SER TEXT X X X 12 char (default: “”)
Date Installed IDT TEXT X X X 8 char (default: “”)
Nominal Float Voltage NFV TEXT X X X 6 char (default: “”)
Nominal Boost Voltage NBV TEXT X X X 6 char (default: “”)
Nominal Current Limit NCL TEXT X X X 6 char (default: “”)
Options Installed OP1-5 TEXT X X X 20 char (default: “”)
Maintenance History CL01-20 TEXT X X X 30 char (default: “”)
Distribution Bay Inventory DBI
Identifier IDE TEXT DI1 to DI2
Description DES TEXT X X X Distrib Bay Inventory n
Remaining Space RSP TEXT X X X 2 char (default: “”)
Panel Inventory PIN
Identifier IDE TEXT PI01 to PI20
Description DES TEXT X X X Panel Inventory n
Bay BAY TEXT X X X 20 char (default: “”)
Number of Slots NSL TEXT X X X 2 char (default: “”)
Remaining Capacity RCP TEXT X X X 6 char (default: “”)
Remaining Space RSP TEXT X X X 2 char (default: “”)
Slot Inventory SLI
Identifier IDE TEXT SLI001 to SLI200
Description of Load DES TEXT X X X Slot Inventory n
Fuse or Circuit Breaker TYP TEXT X X X 4 char (default: “”)
Fuse/Circuit Breaker Size SIZ TEXT X X X 8 char (default: “”)
Reserve Battery Inventory RBI
Identifier IDE TEXT RI1
Description DES TEXT X X X Reserve Battery Inventory 1
Type of Batteries TYP TEXT X X X 15 char (default: “”)
Vendor VND TEXT X X X 12 char (default: “”)
Number of Cells NUM TEXT X X X 2 char (default: “”)
Reserve Time RTM TEXT X X X 2 char (default: “”)
Reserve Load RLD TEXT X X X 6 char (default: “”)
Battery String Inventory STI
Identifier IDE TEXT STI01 to STI20
Description DES TEXT X X X Battery String Inventory n
Date Installed IDT TEXT X X X 8 char (default: “”)
Maintenance History CL01-10 TEXT X X X 30 char (default: “”)
