Tyco Electronics Galaxy SC Controller J85501F-1
Issue 13 February 2001 Installation 3 - 15
Memory Battery Insert the memory battery provided into the BJH (Intelligent Controller)
circuit pack (if equipped) X201 battery holder. Observe proper polarity;
the battery holder clip contacts the “+” side of the memory battery. Take
care not to flex the battery holder clip excessively.
Controller Fusing Remove the BASIC, INTEL and PER MON fuses from the BJF
Fuse/Termination board located to the right of the Basic side circuit
packs, using the fuse puller provided. Insure that all other fuses on this
board are fully engaged. See Figure 3-2.
BJH
Intelligent
processor
SW203-8 0
Remote rectifier in
standby
Enabled Disabled
SW203-7 0
Remote rectifier turn
on
Enabled Disabled
SW203-6 1
Full access through
local port
Enabled User Only
SW203-5 1
Full access through
auxiliary port
Enabled User Only
SW203-4 1
Full access through
modem port
Enabled User Only
SW203-3 1
Modem/aux/local
port setting
configuration
Enabled Disabled
SW203-2 0 Local port: Event Log Terminal
SW203-1 1 Auxiliary port RS232 RS485
SW204 4-8 0 Not used Enabled Disabled
SW204-3 0
Enhanced remote
security
Enabled Disabled
SW204-2 0 Remote alarm test Enabled Disabled
SW204-1 0
Rectifier efficiency
algorithm
Enabled Disabled
Table 3-D: Switch Positions for Galaxy Controller Basic
and Intelligent Boards
Circuit Pack Switch Pos Default Description Closed Is (1) Open Is (0)
