SECTION 2. SPECIFICATIONS
1) GEAR PUMP
MODEL T303HST/T353HST
Delivery (cc/rev) 6.5
Maximum pressure (kgf/㎤)
180
Rated operation speed (rpm) 500~3500
Rotation direction C.C.W as viewed from shaft
2. Power steering valve Unit(orbitrol)
MODEL T303HST/T353HST
Model number OSPM 80 ON
Displacement (cc/rev) 80
Rated flow (ℓ/min) 7~20
Maximum system pressure (kgf/㎤)
180
Max. back pressure (kgf/㎤)
20
Max. temperature(℃) 90
Input torque (N.m) 0.8~1.5
Inlet relief pressure setting (kgf/㎤)
110~115
Recommended filtration (ISO4406) 22/20/17
Weight (kgf) 2.7
3. OIL TANK
MODEL T303HST/T353HST
TANK TRANS MISSION
Fluid volume (ℓ) 35
Fluid THF500
8-2
