TYM T303HST User Manual

SECTION 2. OPERATION CHART FOR DISASSEMBLY AND
REASSEMBLY BY MAJOR BLOCKS
Axle Bracket
Front Axle
Engine
Front
Transmission
Space
transmission
•Power steering
•Air cleaner
•Radiator
•Oil cooler
•Center pivot
•Final case
•Differential gear
•Muffler
•HST UNIT
•PTO Clutch
•Flow-Divider
•
HST control linkage
•Engine front parts
2-4
Rear
transmission
Cylinder case
Brake case
Rear Axle Housing
•Mid PTO gears
•Valve system
•Control linkage
•Piston and Arm
•Ring gear
•Differential gear
•Rear PTO gear
•Brake
•Diff-Lock (RH)
•Final gear
•Wheel shaft
•
HST control linkage
•Speed range gears
•Drive pinion
