Fig. 9-30 Filter
1)GENERAL DESCRIPTION
The tractor is equipped with two oil filters:
suction filter(1) and line filter(4),for better
filtration.
2) SPECIFICATIONS
-Suction filter
4) REPLACEMENT
Check the O-rings for damage or deformation
and replace defective ones.When installing the
filters,be sure to install the O-rings properly
with grease applied.
Line filter
Fig. 9-31
Rated flow rate(ℓ/min.) 35
Filtration density (mesh) 150 mesh
Filtration area
450 ㎠
㎠㎠
㎠
Working oil temperature (℃) -30 ∼130℃
3) Line filter
Applicable oil DONAX TD or
RPM THF 500
Filtration density (mesh) 80 mesh
9-15
