TYM T303HST - Section 5. Earthing Point

SECTION 5. EARTHING POINT
Fig.10-24
1) Fuel tank guard (RH)
1
3
2
2) Contact surfaces of the Hood frame and
bracket where they tightened together
10-12
Earthed at tapped hole in the lower the working lamp
A
Fig.10-25
Fig.10-26 Hood frame
