TYM T303HST User Manual

Part names and
inspection items
Nominal
dimensions
Standard value
for reassembly
Usable limits Service instructions
and remarks
5.REAR AXLE (CHAPTER 7)
1) DISK BRAKE
FRICTION
PLATE
THICKNESS
(WEAR AND
CARBONIZER )
4.7 ± 0.1 ㎜ 4.2 ㎜
2)SEPARATE PLATE
Thickness
(wear and damage)
2.5 ± 0.09 ㎜ 2.5 ㎜
3) BRAKE ROD TURN BUCKLE
Pedal play at the
top
30 ∼40 ㎜
6. POWER STEERING SYSTEM( CHAPTER 8)
11-4
6. POWER STEERING SYSTEM( CHAPTER 8)
1) GEAR PUMP
Capacity
6.5 ㏄/rev (15.3 ℓ/min)
Theoretical value/revolution
N=2600 rpm, P=150 ㎏f/㎠
Oil temperature : 50 ± 5 ℃
Direction of
revolution
CCW at 500 ∼ 3500 rpm
7.HYDRAULIC SYSTEM (CHAPTER 9)
1) PISTON AND CYLINDER
cylinder and bore
Ø 75 ㎜
0-ring : Ø65㎜
