TYM T303HST User Manual

Part names and
inspection items
Nominal
dimensions
Standard value
for reassembly
Usable limits Service instructions
and remarks
(2) DIFFERENTIAL
Backlash between
dif-pinion and dif-
side gear
0.1 ∼ 0.2 ㎜ 0.5 ㎜
Pinion thrust collar or
gear
4.FRONT AXLE (CHAPTER 6)
1) Front drive axle (4WD)
Tire inflation
Front : 2.2 ㎏f/㎠
Rear : 1.8 ㎏f/㎠
Wheel alignment
①Toe-in : 2 ∼ 6 ㎜
②Camber : 3 °±1 °
③Caster : 1 °±1 °
④Rocking angle : 5 °±1 °
⑤Steering angle : 52°±1°
Front
center
pivot
shaft.dia.
Ø 50 ㎜ Ø 49.9 ㎜ wear limit : 0.1 ㎜
bush
50
×
55
×
20
Ø 50
㎜
Ø 55.35
㎜
wear limit : 0.2
㎜
11-3
pivot
bush
50
×
55
×
20
Ø 50
㎜
Ø 55.35
㎜
wear limit : 0.2
㎜
Rear
center
pivot
shaft.dia.
Ø 75 ㎜ Ø 74.9 ㎜ wear limit : 0.1 ㎜
bush
75 ×80 ×30 Ø 75 ㎜ Ø 75.2 ㎜ wear limit : 0.2 ㎜
Play in bush
0.3 ㎜
Thrust play
0 ∼ 0.2 ㎜ 0.5 ㎜
Adjust with adjusting
bolt
DIFFE
RENT
IAL
Pinion
gear
0.05 ∼0.06 ㎏f·m
Starting
torque
6~7 ㎏f-cm
Thrust play
0.1 ∼ 0.3 ㎜ shim:0.1, 0.2 ㎜
Drive pinion/ring
gear backlash
0.1 ∼ 0.2 ㎜ shim:0.1, 0.2 ㎜
