SECTION 7. REPAIR
1.TRACTOR SPLITTING (FRONT)
Note: It is not necessary to remove the flywheel
housing from the engine unless engine is
being removed.Split the tractor between the
tunnel and flywheel housing as outlined in
the story below.
Prepare the Tractor:
1.Remove any mid or front attachments and mid .
2.Park tractor on a level surface.Engage park
brake,shut off engine.
3.Disconnect battery negative terminal.
4.Remove floor mat.
5.Remove the operator’s platform.
6.Remove LH and RH closeout panels.
7.Remove seat and seat platform.
8.Remove fenders.
9.Cycle all hydraulic controls to relieve system
pressure.
13.Disconnect two work port tubes form SCV
14.Remove two cap screws and two spacers that
attach tube support bracket to frame. Remove
tube support bracket and as an assembly.
To avoid injury from escaping
hydraulic oil under pressure ,relief the
Note: Hydraulic reservoir contains approximately
26L(6.8gal) of oil.Have a suitable container
ready to catch drain oil.
10.Drain hydraulic reservoir.
11.If tractor is equipped with SCV,raise RH rear
of tractor and support on suitable stands.
12.Remove RH rear wheel and tire.
tube support bracket and as an assembly.
15.Install RH rear wheel and tire.
16.Locate and disconnect all electrical connectors
attaching wiring harness switches and lights on
rear half of tractor.Unfasten wiring harness
from cable clips and move harness away from
rear half of tractor.
4-17
CAUTION:
hydraulic oil under pressure ,relief the
pressure in the system by stopping the
engine and operating all hydraulic
control valves.
