ENKOFORM VMK
4.2.4.2 Up to 120x120 cm
Components pro waler row:

Dimensionsofthecolumn[cm]

70/70 80/80 90/90 100/100  110/110 120/120
**

WalerMK‐120/1,625
2 2 2 2 2 4
WalerMK‐120/1,375
2 2 2 2 2 0
CornerconnectorMK
2 2 2 2 2 2
Wedge
12 12 12 12 12 12
Waler‐VM20Clamp
8 8 12 16 20 22
Waler‐VM20angularclamp
‐ ‐ ‐ ‐ ‐ 2
OutsidecornerheadMK
4 4 4 4 4 4
Platenut15
4 4 4 4 4 4
Tierod1m
2 2 2 2 2 2
From65 x65cm  to 92 x92cm
From90x90cm  to 120x120cm
**

____________________________________________________________________________________
_
**Inthecaseof120x120columns,4WALERSMK/1.625willbeusedprorow.
