Unicum NERO TOUCH - APPENDIX B.4 - HYDRAULIC CIRCUIT for NERO TOUCH INSTANT

User manual for NERO TOUCH, NERO TOUCH INSTANT
page 115
Version 1.0 / June 2017
ТМ
APPENDIX B.4 - HYDRAULIC CIRCUIT FOR NERO TOUCH INSTANT
Coffee
Electrovalve water supply
Pump EX7GW
Angle G1/2
Water filter
Float chamber
Boiler
Water overfow
Water supply
Water
Water
Water
Boiler pump
EX5GW
Milk
Chocolate
Vanilla
Group of mixers
Water (temperature= 92-98
0
C)
Water (temperature= 92-98
0
C)
Water (temperature= 92-98
0
C)
Water (temperature= 92-98
0
C)
