The vending machines can also be connected directly to the water supply mains, taking into considera-
tion the applicable laws of the country of use. The inlet nozzle for connection to the water supply mains is
situatedontherearpanelofthevendingmachine(seeg.5.4)andcomprisesofathreadedconnectorof
diameter ¾”. The machine is connected using a pipe, which can handle the pressure of the water supply
and which is suitable for use with food products (minimum inner diameter of 6mm).
The water pressure in the supply line must be in the range of 0.05 to 0.85 MPa (0.5 – 8.5 bar).
Before connecting the vending machine to the water supply mains: (old connection):
•In accordance with the instruction to the Congurator program (see at the website: www.
unicum.ru), go to the (Coffee) tab and in the (Water container)eldselect(Not installed).
CreatethecongurationleandplaceittotheUSBashdrive.Inaccordancewiththisman
-
ual“load”theleintothevendingmachinesoftware.Withoutcarryingoutthisitemtherest
items are meaningless (the settings will have no effect).
• Set the switch on the switch board of the machine to position [O/OFF] (seeg.5.4pos.2);
• Unplugthemachinebyremovingtheplugfromthepowersocket;
• Removethevendingmachine’srearpanelbyremovingthescrews;
• Disconnectthepumpconnectors(seeg.4.17аand4.17bpos.1,2);
• Disconnectthesiliconetube(seeg.4.17аand4.17bpos.3);
• Connectthesiliconetubeandpowerconnectorstotheelectricvalve(seeg.4.17b);
• Fixtherearwallbackinitsplace;
• Plugthepowercordintoanelectricaloutlet;
• Set the switch on the switch board of the machine to position [I/ON] (seeg.5.4pos.2).
4.3.3 Connecting the vending machine to water supply mains (optional)
Fig.4.17а Fig 4.17b
2
1
3
1
2
3
3
2
1
Fig.4.17c
