7.0 VENDING MACHINE’S WORKING PRINCIPLE
Milk cooling module
(cooler)
~220В
Vending machine
NERO
Milk
Option
~220В Water
Stand NERO TO GO
(payment module)
MDB
Option
Milk cooling module (cooler)
• Cooling system: cools stored milk
• Milk container: milk storage
Vending machine
• Makes and doses hot drinks
• Steam boiler: generates steam for milk foaming (FRESH MILK)
Payment module
• Allows you to make cash and / or non-cash payments
• Storing cups and other accessories for drinks
The vending machine performs making and selling coffee-based drinks with the addition of soluble in-
gredients and instant coffee drinks, as well as adding foamed milk into drinks for vending machines with the
FRESH MILK option. After the customer chooses a drink by touching the drink icon, the vending machine
automatically makes and gives out the selected drink.
Inthecaseofpaymentmoduleinstalledthecustomershoulddepositacreditforthedrinkrstandthen
touch the icon with the selected drink.
 Tomaketheprocessmoreinteractiveorvisible,thedrinkdisposalsectionisttedwithanLEDboard,
which changes its colour, depending on the process underway inside the machine
 Tomaketheprocessmoreinteractiveorvisible,thedrinkdisposalsectionisttedwithanLEDboard,
which changes its colour, depending on the process underway inside the machine:
• Bluecolour-thedrinkwasprepared;
• Red colour - the drink is prepared.
After the drink preparation process is completed the colour of the LED light changes from red to blue and
a single audio signal is given.
The drink preparation and disposal operation comprises of the following steps (see below).
7.1 Placement of the cup
Before choosing a drink place the cup into the compartment for giving out drinks. Then select the image of
the drink on the touch screen.
Forsmallcups,thespecialfoldingheightadjustableshelfisprovidedinthecompartment(seeg.5.1pos.7).
To avoid spilling over of the drink, into the disposal area tray, please make sure to place the cup
in the disposal tray before selecting the drink!
