APPENDIX B - SP2100 2D Imager Setup Barccodes, con’t
BarcodeGuy.com® - UnionNet SP2100 User’s Guide
2D Imager
Only
Programming “ON”
Programming “OFF”
Figure B.0
Instructions: To change the option, first scan the Programming “ON” barcode.
Then scan the Option Code. Finally scan the Programming “OFF” barcode.
41
B.24 - QR Code
Set QR Code
Factory Defaults
Enable
QR Code
Disable
QR Code
PDF417 twin code is a combination of two PDF417 barcodes, paired either vertically (on top) or horizontally (side by side). They must
be encoded in the same direction. They must have the same resolution with little white/quiet zones between them. There are 3 options
for reading PDF417 twin code:
● Single PDF417 Only: Read either PDF417 code.
● Twin PDF417 Only: Read both PDF417 codes. The transmission sequence is: left (upper) PDF417 code followed by right (lower)
PDF417 code.
● Both Single & Twin: Read both single and twin PDF417 codes.
Min and Max String Lengths - To limit the length of the barcode string as a form of validation, you can set a minimum and
maximum string length. These lengths include check and stop/start digits if applicabl to the symbology. To set the string length:
Set QRCode
Max Code Length
(Default = 7089)
Set QRCode
Min Code Length
(Default = 1)
NOTES: * String length must be less than 65535 bytes.
* MAX LENGTH must be less than or equal to MIN LENGTH.
* If MIN LENGTH = MAXLENGTH, only that single length barcode
string will be allowed.
1. Scan the Programming “ON” barcode.
2. Scan the Set Min Length barcode, then scan the digit code(s) from Section B.29 of this Appendix (B) for the number representing
the minimum length.
3. Scan the Save Programming barcode.
4. Scan the Set Max Length barcode, then scan the digit code(s) from Section B.29 of this Appendix (B) for the number
representing the minimum length.
Single QRCode
Only
Single & Twin
QRCode
Twin QRCode
Only
B.25 - Aztec
Enable
Aztec
Disable
Aztec
Set Aztec
Factory Defaults
To Next Page
