UPONOR CONTROL SYSTEM WIRED - INSTALLATION AND OPERATION MANUAL
38
11 Maintenance
The maintenance of the Uponor Control System Wired includes
the following:
• Manual preventive maintenance
• Automatic preventive maintenance
• Corrective maintenance
11.1 Manual preventive maintenance
The Uponor Control System Wired requires no preventive
maintenance except cleaning:
1. Use a dry soft cloth to clean the Control System and all its
components.
11.2 Automatic preventive maintenance
Uponor Control System Wired is fitted with an automatic exercise
function. This function consists of a test run designed to prevent
the pump and actuators from seizing up due to inactivity.
This exercise is run every 6 days ±24 hours at random:
• The pump exercise operates only if the pump has not been
activated since the last exercise. The pump is activated 3
minutes during the exercise.
• The actuators exercise operates only if the actuators have not
been activated since the last exercise. The exercise consists of
opening and completely closing the actuators:
• 5 minutes to open an actuator
• 9 minutes to close an actuator
11.3 Corrective maintenance
11.3.1 Fallback mode
If a thermostat is short-circuited or not detected, the controller
executes the fallback mode to maintain the temperature in the
room (heating or cooling) until the problem is resolved.In fallback
mode the actuators will be controlled as follows:
• 7 min open
• 14 min closed
If the wire is broken, the preceding thermostat in order control
the actuators. If this is not possible, the fallback mode will be
activated.
11.3.2 Resetting the controller
If the controller does not work as expected, for example due to a
hang-up, it can be reset to solve the problem:
1. Disconnect and reconnect the controller to AC power.
11.4 Troubleshooting
The table below shows problems and alarms that can occur with
the Uponor Control System and describes solutions.
Stop!
Do not use any detergents to clean the Uponor
System components.
