UPONOR CONTROL SYSTEM WIRED - INSTALLATION AND OPERATION MANUAL
17
4.5 Connecting the controller to AC power
To conclude the installation of the controller:
1. Check that all wiring is complete and correct:
• Thermostats
• Actuators
• Timer
• Heating–cooling switch
• Circulation pump
2. Ensure that the 230 V AC compartment of the controller is
closed and the fixing screw is tightened.
3. Connect the power cable to a 230 V AC wall socket.
