6. SHAFT SYNCHRONIZATION APPLICATION – PARAMETER LISTS
On the next pages you will find the lists of parameters within the respective parameter groups. The
parameter descriptions are given on pages 32 to 85.
Column explanations:
Code = Location indication on the keypad; Shows the operator the present param. number
Parameter = Name of parameter
Min = Minimum value of parameter
Max = Maximum value of parameter
Unit = Unit of parameter value; Given if available
Default = Value preset by factory
Cust = Customer’s own setting
ID = ID number of the parameter
= On parameter code: Parameter value can only be changed after the FC has been
stopped.
= Apply the Terminal to Function method (TTF) to these parameters (see chapter 3)
6.1 Monitoring values (Control keypad: menu M1)
The monitoring values are the actual values of parameters and signals as well as statuses and
measurements. Monitoring values cannot be edited.
See the product's User's Manual for more information.
Code Parameter Unit ID Description
V1.1 Output frequency Hz 1 Output frequency to motor
V1.2 Frequency reference Hz 25
Frequency reference to motor
control
V1.3 Motor speed rpm 2 Motor speed in rpm
V1.4 Motor current A 3
V1.5 Motor torque % 4 In % of Motor nominal torque
V1.6 Motor power % 5 Motor shaft power
V1.7 Motor voltage V 6
V1.8 DC link voltage V 7
V1.9
Unit temperature
°C
8 Heatsink temperature
V1.10 Motor temperature
%
9 Calculated motor temperature
V1.11
Analogue input 1
V/mA
13 AI1
V1.12
Analogue input 2
V/mA
14 AI2
V1.13 DIN1, DIN2, DIN3 15 Digital input statuses
V1.14 DIN4, DIN5, DIN6 16 Digital input statuses
V1.15 Analog Iout MA 26 AOA1
V1.16 Torque reference
%
18
V1.17 Actual ratio*2^16 1700 Actual synch. ratio
V1.18 Position error
u
1701 Psotion error in user unit
V1.19 Encoder 1 Freq
Hz
1124
Shaft Frequency filtered
V1.20 Encoder 2 Freq
Hz
53
Master encoder frequency
V1.21 Pole pair number
58
Calculated pole pair number
based on given motor data
V1.22 ID Run Status
49
Status of ID run made
V1.23 Trial time left
h
67
Hours left of trial time
V1.24 Accum Space Error
u
1803
Displays accumulated position
error when follower not
running in synch. mode.
G1.25 Multimonitoring items
Displays three selectable
monitoring values
Table 2. Monitoring values
