shaft synchronization application – parameter lists vacon • 25
24-hour support +358 (0)40 837 1150 • Email: vacon@vacon.com
6
P2.5.18.8
Magnetizing time
at start
0,000 60,000 s 0,0 628
P2.5.18.9
0-speed time at
start
0 32000 ms 100 615
P2.5.18.10
0-speed time at
stop
0 32000 ms 100 616
P2.5.18.11 Start-up torque 0 3 0 621
0=Not used
1=Torque memory
2=Torque reference
3=Start-up torque fwd/rev
P2.5.18.12
Start-up torque
FWD
–300,0 300,0 s 0,0 633
P2.5.18.13
Start-up torque
REV
–300,0 300,0 s 0,0 634
P2.5.18.14 Encoder filter time 0 100,0 ms 0 618
P2.5.18.15
Current control
P gain
0,00 100,00 % 40,00 617
P2.5.18.16 KpF1 spd thresld P2.5.18.17 P2.1.2 Hz 2,00 1555
Frequency threshold for
transition to normal speed
regulator gain
P2.5.18.17 KpF0 spd thresld 0,00 P2.5.18.16 Hz 1,00 1556
Frequency threshold for
transition to low speed
regulator gain
P2.5.18.18 %Kp spd reg @ F0 0 100 % 50 1557
Speed regulator gain at
low speed, as a percent-
age of normal gain
(P2.5.18.2)
P2.5.18.19 Stop State Flux 0,0 150,0 % 100,0 1401
Stop state magnetization
current in % of nominal
magnetizing current
P2.5.18.20 Flux Off Delay -1 32000 s 0 1402
Maximum time for stop
state magnetization
Table 18. Motor control parameters, G2.5
6.6.1 PMSM settings (Control keypad: Menu M2  G2.5.19)
Code Parameter Min Max Unit Default Cust ID note
P2.5.19.1 Motor type 0 1 0 650
0=Asynchronous motor
1=PMS Motor
P2.5.19.2 FluxCurrent Kp 0 32000 500 651
Gain for flux current
control
P2.5.19.3 FluxCurrent Ti 0 1000 ms 50 652
Integral time for flux
control
P2.5.19.4
PMSMShaft
Position
0 65535 0 649
Low word of encoder
angle corresponding to
the shaft 0 position
P2.5.19.5 EnableRsIdentific 0 1 1 654
Enable Rs identification
during DC brake at start
P2.5.19.6 ModIndexLimit 0 200 100 655
Modulaton index limit at
field weakening point
Table 19. Parameters for permanent magnet synchronous motor, G2.5.19
