76 • vacon description of parameters
Tel. +358 (0)201 2121 • Fax +358 (0)201 212 205
7
1 5 Motor power 0.1% of motor
nominal power
1 6 Motor voltage 0.1 V
1 7 DC link voltage 1 V
1 8 Unit temperature 1 ° C
1 9 Motor temperature 1 % of nominal
overtemperature
1 13 Analogue input 1 1 count = 1/10000 of
range, conversion
resolution 10 bit
1 14 Analogue input 2 1 count = 1/10000 of
range, conversion
resolution 10 bit
1 15 DIN1*2
0
+DIN2*2
1
+DIN3*2
2
1 16 DIN4*2
0
+DIN5*2
1
+DIN6*2
2
1 26 Analog out 2000 count at full
scale
1 18 Torque reference 0.1 %
Table 37. Output variables for use with process data outputs
1401 Stop State Flux
(P2.5.18.19)
The amount of flux as a percentage of the motor nominal flux maintained in the motor
after the drive is stopped. The flux is maintained for the time set by parameter ID1402.
This parameter can be used in closed loop motor control mode only.
1402 Flux Off Delay
(P2.5.18.20)
The flux defined by parameter ID1401 is maintained in the motor for the set time after
the drive is stopped.
0 No flux after the motor is stopped.
>0 The flux off delay in seconds.
<0 The flux is maintained in the motor after stop until the next Run request is given to
the drive.
NOTE: Using of stop state flux is useful when there is a large motor which has a relative
long magnetizing time and the motor is started frequently (inching). Then the motor is
already magnetized and ready to run.
