Vacon NXP User Manual

shaft synchronization application – parameter lists vacon • 21
24-hour support +358 (0)40 837 1150 • Email: vacon@vacon.com
6
6.4.5 Analogue output 1 (Control keypad: Menu M2  G2.3.5)
Code Parameter Min Max Unit Default Cust ID Note
P2.3.5.1
Analogue output 1
signal selection
0 A.1 464
P2.3.5.2
Analogue output 1
function
0 14 1 307
0=Not used
1=Output freq. (0—f
max
)
2=Freq. reference (0—f
max
)
3=Motor speed (0—Motor
nominal speed)
4=Motor current (0—I
nMotor
)
5=Motor torque (0—T
nMotor
)
6=Motor power (0—P
nMotor
)
7=Motor voltage (0-U
nMotor
)
8=DC-link volt (0—1000V)
9=AI1
10=AI2
11=Output freq. (f
min
- f
max
)
12=Motor torque
(–2…+2xT
Nmot
)
13=Motor power
(–2…+2xT
Nmot
)
14=PT100 temperature
P2.3.5.3
Analogue output 1
filter time
0,00 10,00 s 1,00 308 0=No filtering
P2.3.5.4
Analogue output 1
inversion
0 1 0 309
0=Not inverted
1=Inverted
P2.3.5.5
Analogue output 1
minimum
0 1 0 310
0=0 mA
1=4 mA
P2.3.5.6
Analogue output 1
scale
10 1000 % 100 311
P2.3.5.7
Analogue output 1
offset
-100,00 100,00 % 0,00 375
Table 13. Analogue output 1 parameters, G2.3.5
6.4.6 Analogue output 2 (Control keypad: Menu M2  G2.3.6)
Code Parameter Min Max Unit Default Cust ID Note
P2.3.6.1
Analogue output 2
signal selection
0 0.1 471
P2.3.6.2
Analogue output 2
function
0 14 4 472 See par. 2.3.5.2
P2.3.6.3
Analogue output 2
filter time
0,00 10,00 s 1,00 473 0=No filtering
P2.3.6.4
Analogue output 2
inversion
0 1 0 474
0=Not inverted
1=Inverted
P2.3.6.5
Analogue output 2
minimum
0 1 0 475
0=0 mA
1=4 mA
P2.3.6.6
Analogue output 2
scale
10 1000 % 100 476
P2.3.6.7
Analogue output 2
offset
-100,00 100,00 % 0,00 477
Table 14. Analogue output 2 parameters, G2.3.6
