Vacon NXP User Manual

30 • vacon shaft synchronization application – parameter lists
Tel. +358 (0)201 2121 • Fax +358 (0)201 212 205
6
6.10 Shaft synchronization parameters (Control keypad: Menu M2  G2.9)
Code Parameter Min Max Unit Default Cust ID Note
MASTER settings group 2.9.1 (See separate section)ettings
P2.9.1.1 Master distance 1 32767 u 360 1750
Master distance in user
units, Integer part
P2.9.1.2
Master distance
fractional
0 65535 u 0 1751
Master distance in user
units, fractional part
P2.9.1.3 Master turns 1 32767 1 1752
Master turns, Interger
part corresponding to
P2.9.1.1 and 2.9.1.2
P2.9.1.4
Master turns
fractional
0 65535 0 1753
Master turns, fractional
part corresponding to
P2.9.1.1 and 2.9.1.2
P2.9.1.5
Master speed filter
TI
0,000 32,767 0,100 1754
Time constant [s] of the
1st order low-pass filter
on master speed meas-
urement
FOLLOWER settings group 2.9.2
P2.9.2.1 Follower distance 1 32767 u 360 1757
Follower distance in user
units, integer part
P2.9.2.2
Follower distance
Fractional
0 65535 u 0 1758
Follower distance in user
units, fractional part
P2.9.2.3 Follower turns 1 32767 1 1759
Follower turns, Interger
part corresponding to
P2.9.1.1 and 2.9.1.2
P2.9.2.4
Follower turns
fractional
0 65535 0 1760
Follower turns, fractional
part corresponding to
P2.9.2.1 and 2.9.2.2
P2.9.2.5
Follower speed
filter TI
0,000 32,767 0,010 1761
Time constant [s] of the
1st order low-pass filter
on follower speed meas-
urement
P2.9.2.6 PID control gain 0 2147483647 30 1762
Proportional gain for
synchroniz. regulator
P2.9.2.7 PID control I gain 2147483647 1 1763
Integral gain for synchro-
nization regulator
P2.9.2.8
Synchronization
acceleration
1 32767 u/s
2
3600 1764
Acceleration for engage
synchronization and de-
celeration for the release
synchronization com-
mands
P2.9.2.9
Electrical Gear
ratio
-262144 262144 65536 1765
Adjust register for chang-
ing of the ratio in run
mode
P2.9.2.10 Ratio ramp time 0,000 2147483,647 ms 10,000 1766
Ramp time in ms for ratio
change according tp
P2.9.2.9
P2.9.2.11 Trim ratio change 0,1 200,0 % 10,0 1767
Setting of how much digi-
tal trim inputs affects the
ratio.
PHASING settings group 2.9.3
P2.9.3.1 Distance -32000 32000 U 1 1805
Distance in user unit for
phasing command.
P2.9.3.2 Sel PosPhasing 0.1 E.10 0.1 1716
Input selection by TTF for
positive phasing
P2.9.3.3 Sel NegPhasing 0.1 E.10 0.1 1717
Input selection by TTF for
negative phasing
Table 23. Parameters for Shaft Synchronization, G2.9
