Vacon NXP User Manual

18 • vacon shaft synchronization application – parameter lists
Tel. +358 (0)201 2121 • Fax +358 (0)201 212 205
6
6.4 Output signals
6.4.1 Delayed digital output 1 (Keypad: Menu M2  G2.3.1)
Code Parameter Min Max Unit Default Cust ID Note
P2.3.1.1
Digital output 1
signal selection
0 0.1 486
P2.3.1.2
Digital output 1
function
0 26 1 312
0=Not used
1=Ready
2=Run
3=Fault
4=Fault inverted
5=FC overheat warning
6=Ext. fault or warning
7=Ref. fault or warning
8=Warning
9=Reverse
10=Jogging spd selected
11=At speed
12=Mot. regulator active
13=Freq. limit 1 superv.
14=Freq. limit 2 superv.
15=Torque limit superv.
16=Ref. limit supervision
17=External brake control
18=I/O control place act.
19=FC temp. limit superv.
20=Reference inverted
21=Ext. brake control
inverted
22=Therm. fault or warn.
23=On/Off control
24=Fieldbus input data 1
25=Fieldbus input data 2
26=Fieldbus input data 3
P2.3.1.3
Digital output 1 on
delay
0,00 320,00 s 0,00 487 0,00 = delay not in use
P2.3.1.4
Digital output 1 off
delay
0,00 320,00 s 0.00 488 0,00 = delay not in use
Table 9. Delayed digital output 1 parameters, G2.3.1
6.4.2 Delayed digital output 2 (Keypad: Menu M2  G2.3.2)
Code Parameter Min Max Unit Default Cust ID Note
P2.3.2.1
Digital output 2
signal selection
0 0.1 489
P2.3.2.2
Digital output 2
function
0 26 0 490 See par. 2.3.1.2
P2.3.2.3
Digital output 2 on
delay
0,00 320,00 s 0,00 491 0,00 = delay not in use
P2.3.2.4
Digital output 2 off
delay
0,00 320,00 s 0,00 492 0,00 = delay not in use
Table 10. Delayed digital output 2 parameters, G2.3.2
