Vacon NXP User Manual

20 • vacon shaft synchronization application – parameter lists
Tel. +358 (0)201 2121 • Fax +358 (0)201 212 205
6
6.4.4 Limit settings (Control keypad: Menu M2  G2.3.4)
Code Parameter Min Max Unit Default Cust ID Note
P2.3.4.1
Output frequency
limit 1 supervision
0 3 0 315
0=No limit
1=Low limit supervision
2=High limit supervision
3=Brake-on control
P2.3.4.2
Output frequency
limit 1;
Supervised value
0,00 Par. 2.1.2 Hz 0,00 316
P2.3.4.3
Output frequency
limit 2 supervision
0 4 0 346
0=No limit
1=Low limit supervision
2=High limit supervision
3=Brake-off control
4=Brake on/off-control
P2.3.4.4
Output frequency
limit 2;
Supervised value
0,00 Par. 2.1.2 Hz 0,00 347
P2.3.4.5
Torque limit
supervision
0 3 0 348
0=Not used
1=Low limit supervision
2=High limit supervision
3=Brake-off control
P2.3.4.6
Torque limit
supervision value
-1000,0 1000,0 % 100,0 349
P2.3.4.7
Reference limit
supervision
0 2 0 350
0=Not used
1=Low limit
2=High limit
P2.3.4.8
Reference limit
supervision value
0,00 Par. 2.1.2 Hz 0,00 351
P2.3.4.9
FC temperature
supervision
0 2 0 354
0=Not used
1=Low limit
2=High limit
P2.3.4.10
FC temperature
supervised value
–10 75
°C
0 355
Table 12. Limit settings, G2.3.4
