Vacon NXP User Manual

14 • vacon shaft synchronization application – parameter lists
Tel. +358 (0)201 2121 • Fax +358 (0)201 212 205
6
6.2 Basic parameters (Control keypad: Menu M2  G2.1)
Code Parameter Min Max Unit Default Cust ID Note
P2.1.1 Max frequency Par. 2.1.1 320,00 Hz 50,00 102
NOTE: If f
max
> than the
motor synchronous speed,
check suitability for motor
and drive system
P2.1.2 Acceleration time 1 0,1 3000,0 s 1,0 103
P2.1.3 Deceleration time 1 0,1 3000,0 s 1,0 104
P2.1.4 Current limit 0,4 x I
H
2 x I
H
A I
L
107
P2.1.5
Nominal voltage of
the motor
180 690 V
NX2: 230V
NX5: 400V
NX6: 690V
110
P2.1.6
Nominal frequency
of the motor
30,00 320,00 Hz 50,00 111
Check the rating plate of
the motor
P2.1.7
Nominal speed of
the motor
300 20 000 rpm 1440 112
The default applies for a 4-
pole motor and a nominal
size frequency converter.
P2.1.8
Nominal current of
the motor
0,4 x I
H
2 x I
H
A I
H
113
Check the rating plate of
the motor.
P2.1.9
Motor cosϕ
0,30 1,00 0,85 120
Check the rating plate of
the motor
P2.1.10 I/O Reference 0 14 0 117
0=AI1
1=AI2
2=AI1+AI2
3=AI1-AI2
4=AI2-AI1
5=AI1xAI2
6=AI1 Joystick
7=AI2 Joystick
8=Keypad
9=Fieldbus
10=Motor potentiometer
11=AI1, AI2 minimum
12=AI1, AI2 maximum
13=Max frequency
14=AI1/AI2 selection
P2.1.11
Keypad control
reference
0 9 8 121
0=AI1
1=AI2
2=AI1+AI2
3=AI1-AI2
4=AI2-AI1
5=AI1xAI2
6=AI1 Joystick
7=AI2 Joystick
8=Keypad
9=Fieldbus
P2.1.12
Fieldbus control
reference
0 9 9 122 See par. 2.1.12
P2.1.13
Jogging speed
reference
0,00 Par. 2.1.2 Hz 5,00 124
P2.1.14 Preset speed 1 0,00 Par. 2.1.2 Hz 10,00 105 Multi-step speed 1
P2.1.15 Preset speed 2 0,00 Par. 2.1.2 Hz 15,00 106 Multi-step speed 2
P2.1.16 Preset speed 3 0,00 Par. 2.1.2 Hz 20,00 126 Multi-step speed 3
P2.1.17 Preset speed 4 0,00 Par. 2.1.2 Hz 25,00 127 Multi-step speed 4
P2.1.18 Preset speed 5 0,00 Par. 2.1.2 Hz 30,00 128 Multi-step speed 5
P2.1.19 Preset speed 6 0,00 Par. 2.1.2 Hz 40,00 129 Multi-step speed 6
P2.1.20 Preset speed 7 0,00 Par. 2.1.2 Hz 50,00 130 Multi-step speed 7
Table 3. Basic parameters G2.1
