36 • vacon description of parameters
Tel. +358 (0)201 2121 • Fax +358 (0)201 212 205
7
122 Fieldbus frequency reference selection
(2.1.12)
Defines which frequency reference source is selected when controlled from the fieldbus.
For selections in different applications, see ID121.
124 Jogging speed reference
(2.1.13)
Defines the jogging speed selected with the DIN3 digital input which can be programmed
for Jogging speed. See parameter ID301.
Parameter value is automatically limited between minimum and maximum frequency
(ID's 101 and 102).
126 Preset speed 3
(2.1.16)
127 Preset speed 4
(2.1.17)
128 Preset speed 5
(2.1.18)
129 Preset speed 6
(2.1.19)
130 Preset speed 7
(2.1.20)
Parameter values define the Multi-step speeds selected with the DIN3, DIN4, DIN5 and
DIN6 digital inputs. See also parameter ID’s 105 and 106.
Parameter value is automatically limited between minimum and maximum frequency
(ID's 101 and 102).
Speed
Multi-step speed
sel. 1 (DIN4)
Multi-step speed
sel. 2 (DIN5)
Multi-step speed
sel. 3 (DIN6)
Multi-step speed
sel. 4 (DIN3)
Basic speed 0 0 0 0
P2.1.16 (3) 1 1 0 0
P2.1.17 (4) 0 0 1 0
P2.1.18 (5) 1 0 1 0
P2.1.19 (6) 0 1 1 0
P2.1.20 (7) 1 1 1 0
Table 29. Preset speeds 3 to 7
141 AI3 signal selection
(2.2.4.1)
Connect the AI3 signal to the analogue input of your choice with this parameter. For
more information, see Chapter 5, on page 10.
142 AI3 signal filter time
(2.2.4.2)
When this parameter is given a value greater than 0 the function that filters out distur-
bances from the incoming analogue signal is activated. Long filtering time makes the
regulation response slower. See parameter ID324.
